ProjectSymbols for CET Designer combines the power of CET Designer with AutoCAD blocks from over 200 manufacturers. Designers can use ProjectSymbols to help create detailed 2D and 3D floor plans and photo quality renderings.

This tool gives designers and sales people a competitive advantage by allowing them access to a huge library of supplemental data to produce amazing 3D renderings and detailed product listings to use for quotes, design layouts, and sales documents. ProjectSymbols for CET Designer follows the industry standard SIF file structure and makes it a seamless process to pass files between other specification tools and order entry systems. The extension also allows the import and export AutoCAD drawings and converts drawings built in ProjectSymbols, Cap Studio, and Design Express to work with CET Designer.


  • Must have a Site License of ProjectSymbols for AutoCAD
  • Standard CET Volume Licenses Apply
  • Per User


  • No ProjectSymbols for AutoCAD licences
  • Standard CET Volume Licenses Apply
  • Per User


  • Quickly specify product options directly in CET Designer

  • Can fully render high-quality symbols from over 200 manufacturers

  • Add non graphical entities to your drawings using the CET Designer pick list feature

  • Up to date catalog data with current pricing included

  • Easily add materials to your graphics to show clients what the products will visually look like in their office environment

  • Build custom option tables to automatically apply options to parts and pieces as they are placed

  • Completely compatible with your other extensions in CET Designer

Minimum Requirements

  • Operating System: Windows 7, 8 and 10

  • Processor: Pentium 4 Quad or faster

  • RAM: 2GB

  • HDD: 1GB  *not including data

  • Resolution: 1024 x 768 / 256 Colors

Recommended Requirements

  • Operating System: Windows 7, 8 and 10

  • Processor: Intel Core i7 or faster

  • RAM: 8GB or more

  • HDD: 1GB  *not including data

  • Resolution: 1600×1050 or higher

ProjectSymbols CET Designer

ProjectSymbols have been added along with manufacturer extensions to a drawing.

ProjectSymbols CET Designer

Pic lab helps you create high quality, photo-realistic renders of manufacturers extension pieces and symbols from ProjectSymbols.

ProjectSymbols CET Designer

Quickly turn a manufacturer’s data on by clicking on their name.

ProjectSymbols CET Designer

You can option the symbol before or after placing it into your drawing.

ProjectSymbols CET Designer

Part preview helps ensure you are placing the correct symbols.

ProjectSymbols CET Designer

Quick render helps you preview your applied materials to a symbol.
